The steel wire rope is DIN standard compliant, with high quality. It's specially used in the electric railways.

Product Structures

• 8×19S-IWR
• 8×19W-IWR
• 8×25Fi-IWR
• 8×26SW-IWR
• 8×31WS-IWR

Specifications

8×19S-IWR, 8×19W-IWR, 8×25Fi-IWR, 8×26SW-IWR, 8×31WS-IWR
Construction	Nominal Dia.(mm)	Tolerance of Dia.(mm)	Min. Breaking Strength(KN)	Approximate Weight (kg/100m)
8×19S 8×19W 8×25Fi 8×26SW 8×31WS	8.0	0/0.56	42.6	28.3
	8.75	0/0.56	54.0	33.9
	9.0	0/0.56	54.0	35.8
	10.0	0/0.56	61.2	44.2
	11.0	0/0.66	74.0	53.2
	12.0	0/0.66	83.3	63.7
	13.0	0/0.82	103	74.8
	14.0	0/0.82	120	86.7
	16.0	0/0.82	156	113
	18.0	0/1.10	187	143
	20.0	0/1.10	231	176
	22.0	0/1.12	296	219
	24.0	0/1.12	332	252
	26.0	0/1.14	390	296
	28.0	0/1.14	453	343
