Fiber count		~24	~48	~24	~48
CSM/Steel wire(mm)		2	2	2.2	2.2
Copper wire (mm2)		4	4	6	6
Element number		4	4	4	4
Max. cores in tube		6	12	6	12
Cable diameter approx.		15.5	16.1	17.5	17.5
Tensile strength (N)	Long term	600
	Short term	1500
Crush Resistance (N/100mm)	Long term	800
	Short term	1000
Bending Radius (mm)	Static	≥12.5×cable diamete
	Dynamic	≥25×cable diameter
Dielectric Strength		2000V
Voltage Grade		2000V
Operating Temperature ℃		20
Application		Aerial and Duct
