Fiber count | 2~12 | |
Max cores in tuber | 12 | |
Cable diameter (mm) | 7 | |
Weight approx (kg/km) | 79 | |
Tensile strength (N) | according to the demand of design | |
Crush resistance (N/100mm) | long term | 300 |
short term | 1000 | |
Bending radius (mm) | dynamic | ≥20× cable diameter |
static | ≥10× cable diameter | |
Operating temperature (℃) | -40 -- +60 | |
Application | Aerial |
