Flat Drop Optical Fiber Cable 2

Product performance
Butterfly drop cable(Figure 1) Self-supporting butterfly drop
cable (Figure 2)
Fiber count 4 (Fiber ribbon) 4(Fiber ribbon) 12(Fiber ribbon)
Attenuation G.652 or G.657
@1310/@1550nm
0.36/0.25 0.36/0.25 0.36/0.25
Cable diameter (mm) 2.0X4.0(±0.1) 2.0X6.0(±0.2) 2.0X8.5(±0.2)
Cable Weight (kg/km) 12 25 28
Tensile strength
(N)
Long term Non-matellic
strength member
40 300
Short term 80 600
Crush Resistance
(N/100mm)
Long term 500 1000
Short term 1000 2200
Bending radius
(mm)
Static 30(G.652) 15(G.657A) 10(G.657B)
Dynamic 60(G.652) 30(G.657A) 25(G.657B)
Operating temperature (℃) -40~+60
Enviromental standards: IEC60332.
Accord with EU ROSH standard. Flame retardant grade accord with IEC60332.
