Fiber count		≤30	32~36	32~60	62~72	74~84	86~96	98~108
CSM/Steel wire (mm)		--/1.45	--/1.8	--/1.6	--/2.2	3.0/2.0	3.6/2.0	4.2/2.0
Element number		5	6	5	6	7	8	9
Max. cores in tube		6	6	12	12	12	12	12
GYDTA/GYDTS(mm) Cable diameter approx	GYTA	9.1	9.5	10	10.6	11.5	12.1	12.7
	GYTS	9.4	9.7	10.1	10.7	11.5	12.1	12.9
GYDTA/GYDTS(kg/km) weight approx	GYTA	80	93	96	119	129	141	154
	GYTA	100	113	118	143	155	168	189
Fiber count		110~120	122~132	134~144	146~216	218~240	242~264	266~288
CSM/Steel wire(mm)		4.8/2.0	5.6/2.0	6.3/2.0	--/2.2	3.0/2.2	3.6/2.2	4.4/2.2
Element number		10	11	12	6+12	7+13	8+14	9+15
Max. cores in tube		12	12	12	12	12	12	12
Cable diameter (mm)	GYTA	13.2	14.1	14.8	15.2	16.0	16.7	17.4
	GYTA	13.5	14.3	15.0	15.6	16.4	17.1	17.8
Weight (kg/km)	GYTA	165	183	199	222	246	268	292
	GYTA	202	222	240	258	284	308	333
Tensile strength (N)	Long term	600
	Short term	1500 and≥ 1G (G-Cable weight)
Crush Resistance (N/100mm)	Long term	300
	Short term	1000
Bending Radius (mm)	Static	≥10×cable diamete
	Dynamic	≥20×cable diameter
Operating Temperature ℃		-40 -- +60
Application		Aerial and Duct
