| Max. allowable working tension (KN) |
Break strength(KN) | Year average working tension (KN) |
Weight (kg/km) | Diameter (mm) | Operation temperature（℃） |
|
| PE sheath | AT sheath | |||||
| 2.5 | 6.25 | 1.56 | 119 | 126 | 12 | -40~+60 |
| 3.5 | 8.75 | 2.19 | 121 | 129 | 12.2 | |
| 4.5 | 11.25 | 2.81 | 124 | 132 | 12.3 | |
| 6 | 15 | 3.75 | 128 | 136 | 12.5 | |
| 7 | 17.5 | 4.38 | 131 | 139 | 12.7 | |
| 8 | 20 | 5 | 134 | 142 | 12.8 | |
| 9 | 22.5 | 5.63 | 136 | 144 | 12.9 | |
| 10 | 25 | 6.25 | 138 | 147 | 13 | |
| 11 | 27.5 | 6.88 | 142 | 150 | 13.1 | |
| 12 | 30 | 7.5 | 144 | 153 | 13.2 | |
| 14 | 35 | 8.75 | 148 | 157 | 13.5 | |
| 16 | 40 | 10 | 154 | 163 | 13.7 | |
| 18 | 45 | 11.25 | 159 | 169 | 14 | |
| 20 | 50 | 12.5 | 164 | 173 | 14.2 | |
Note: 1）Only a part of ADSS cables are list in the table,2～36 fibers in the ADSS cable;
2）Potevio Fasten will design the cable depending on the request of climate, span, voltage degree for customer.
