Fiber count		2~48	50~84	86~96	98~108	110~120	122~132	134~144
CSM/FRP(mm)		--/3.0	--/3.0	--/3.6	4.2/3.6	4.8/3.6	5.6/4.0	6.3/4.0
Element number		8	7	8	9	10	11	12
Max. cores in tube		6	12	12	12	12	12	12
Cable diameter (mm)		10.2	10.8	11.6	12.2	12.8	13.6	14.3
Weight (kg/km)		92	103	120	132	144	164	179
Tensile strength （N）	long term	600
	short term	1500
Crush Resistance (N/100mm)	long term	300
	long term	1000
Bending Radius （mm）	dynamic	≥20×Cable Diameter
	static	≥10×Cable Diameter
Operating Temperature (℃)		-40 -- +60
Application		Aerial, duct, direct burial
