Planetary Wire Stranding Machine

The planetary stranding machine is a must in the metal product industry. Wire ropes which are made by this equipment can be widely applied in the oilfield, port, shipbuilding, mining, manufacturing and other industries.

Specifications of the Planetary Cage-Type Stranding Machine
NO. Model Spool Quantity Stranding Diameter Rotating Speed (r/m) Support Form
Min. Max.
1 500 (18+18)/(12+18+24) 8 50 80 Roller/Bearing
2 630 8/18/(18+18)/(12+18+24)/(36+48) 9 70 60- 80 Roller/Bearing
3 800 8/18/(18+18) 15 80 50-80 Roller/Bearing
4 1000 8 20 55 60 Roller
5 1250 8 30 80 40 Roller
6 1600 8 40 120 35 Roller
7 1800 8 60 150 30 Roller
8 8/1250+8/630 24 100 30 Roller
9 12/500+18/500+24/630 10 60 60 Roller/Bearing

P.S.: Customization is available for the types which are not listed above.
